ATmega328/P Summary
(file size: 401KB, 24 pages, revision A, updated: 06/2016)
ATmega328/P
ATmega328/P Complete
(file size: 5.14MB, 444 pages, revision A, updated: 06/2016)
More Documents...
The high-performance Atmel picoPower 8-bit AVR RISC-based microcontroller combines 32KB ISP flash memory with read-while-write capabilities, 1024B EEPROM, 2KB SRAM, 23 general purpose I/O lines, 32 general purpose working registers, three flexible timer/counters with compare modes, internal and external interrupts, serial programmable USART, a byte-oriented 2-wire serial interface, SPI serial port, a 6-channel 10-bit A/D converter (8-channels in TQFP and QFN/MLF packages), programmable watchdog timer with internal oscillator, and five software selectable power saving modes. The device operates between 1.8-5.5 volts.
By executing powerful instructions in a single clock cycle, the device achieves throughputs approaching 1 MIPS per MHz, balancing power consumption and processing speed.





STM32 F1 series of mainstream MCUs

ST¨s STM32 F1 series of mainstream MCUs covers the needs of a large variety of applications in the industrial, medical and consumer markets. With this series, ST has pioneered the world of ARM® Cortex™-M microcontrollers and set a milestone in the history of embedded applications. High performance with first-class peripherals and low-power, low-voltage operation is paired with a high level of integration at accessible prices with a simple architecture and easy-to-use tools.

The series consists of five product lines which are pin-to-pin, peripheral and software compatible.



MT8816

8 x 16 Analog Switch Array



MT8870 DTMF decoder module telephone voice module
